why "global horizontal illuminance" is smaller than "global horizontal radiation" multiplied by 179 in epw file?

Hi Andy,

Interesting rule. Could you recommend further reading for my interest on how to get to the number 179? I would like to get a tiny grasp on the underlying principle to better understand.

Thanks a lot,
Aksel

···

Am 02.01.2013 um 20:23 schrieb Andrew McNeil <[email protected]>:

Hi Ji,

179 is the efficacy of white (equal energy) light over the visible spectrum.

Daylight is composed of a broader spectrum, so the efficacy (visible light per watt of energy) is lower. Usually around 90 for the sun and 110 for the sky, but changes based on various factors.

179 is used in Radiance as a convention since we are simulating visible light. So when you're defining you sky using gensky with weather data you need to either use the measured illuminance values and divide by 179 to get radiometric units for the visible spectrum, or use the measured radiance values (for solar spectrum), multiply by an approximate efficacy, then divide 179 to get radiometric units for the visible spectrum only.

If you use gendaylit all the conversions are done for you.

Best,
Andy

On Tue, Jan 1, 2013 at 8:36 AM, Ji Zhang <[email protected]> wrote:
Dear list, Happy New Year!

I have a simple question related to conversion from irradiance value to illuminance value, and pls correct me if I'm wrong:

Usually we can estimate the illuminance (lux) for a given point by multiplying the irradiance (w/m2) for the point as simulated via Radiacne by 179 (lm/w) which is the luminous efficacy used in Radiance, or more strictly (R*0.265+G*0.670+B*0.065)*179.

However, it seems that in a epw weather file the "global horizontal illuminance" value is not equal to but smaller than the "global horizontal radiation" value multiplied by 179.

May I ask:
1. why there's such a large discrapency?
2. Will this lead to over-estimation of illuminance when using cumulative sky derived from "global horizontal radiation" ?

Thanks in advance!

- Ji

_______________________________________________
Radiance-general mailing list
[email protected]
http://www.radiance-online.org/mailman/listinfo/radiance-general

_______________________________________________
Radiance-general mailing list
[email protected]
http://www.radiance-online.org/mailman/listinfo/radiance-general

--

Aksel Groß
Dipl.Ing.Arch., Dipl.Szeno.

Electric Gobo
Schönhauser Allee 182
10119 Berlin, Germany

T +49 30 559 531 75
M +49 179 394 30 92
[email protected]

http://gobo.io

my take is, flux / power, therefore:

683 x v_lamda_norm x power

···

---------------------
(780 - 380) x power

and power is =1, constant on the spectrum so it does not matter.
if you measure the area of V_lambda from a normalised chart and multiply by 683, you should get it.
I got 179.75, but the measure was a bit iffy :slight_smile:

On 4 Jan 2013, at 19:47, Andrew McNeil <[email protected]> wrote:

Hi Aksel,
Unfortunately I don't have sources for this other than Greg's emails in the vintage radiance digests (1990's). Search these pages for "179", there are several emails on this topic):
http://radsite.lbl.gov/radiance/digests_html/v2n5.1.html
http://radsite.lbl.gov/radiance/digests_html/v2n9.html
Best,
Andy

On Fri, Jan 4, 2013 at 10:34 AM, Aksel Groß <[email protected]> wrote:
Hi Andy,

Interesting rule. Could you recommend further reading for my interest on how to get to the number 179? I would like to get a tiny grasp on the underlying principle to better understand.

Thanks a lot,
Aksel

Am 02.01.2013 um 20:23 schrieb Andrew McNeil <[email protected]>:

> Hi Ji,
>
> 179 is the efficacy of white (equal energy) light over the visible spectrum.
>
> Daylight is composed of a broader spectrum, so the efficacy (visible light per watt of energy) is lower. Usually around 90 for the sun and 110 for the sky, but changes based on various factors.
>
> 179 is used in Radiance as a convention since we are simulating visible light. So when you're defining you sky using gensky with weather data you need to either use the measured illuminance values and divide by 179 to get radiometric units for the visible spectrum, or use the measured radiance values (for solar spectrum), multiply by an approximate efficacy, then divide 179 to get radiometric units for the visible spectrum only.
>
> If you use gendaylit all the conversions are done for you.
>
> Best,
> Andy
>
>
> On Tue, Jan 1, 2013 at 8:36 AM, Ji Zhang <[email protected]> wrote:
> Dear list, Happy New Year!
>
> I have a simple question related to conversion from irradiance value to illuminance value, and pls correct me if I'm wrong:
>
> Usually we can estimate the illuminance (lux) for a given point by multiplying the irradiance (w/m2) for the point as simulated via Radiacne by 179 (lm/w) which is the luminous efficacy used in Radiance, or more strictly (R*0.265+G*0.670+B*0.065)*179.
>
> However, it seems that in a epw weather file the "global horizontal illuminance" value is not equal to but smaller than the "global horizontal radiation" value multiplied by 179.
>
> May I ask:
> 1. why there's such a large discrapency?
> 2. Will this lead to over-estimation of illuminance when using cumulative sky derived from "global horizontal radiation" ?
>
> Thanks in advance!
>
> - Ji
>
> _______________________________________________
> Radiance-general mailing list
> [email protected]
> http://www.radiance-online.org/mailman/listinfo/radiance-general
>
>
> _______________________________________________
> Radiance-general mailing list
> [email protected]
> http://www.radiance-online.org/mailman/listinfo/radiance-general

--

Aksel Groß
Dipl.Ing.Arch., Dipl.Szeno.

Electric Gobo
Schönhauser Allee 182
10119 Berlin, Germany

T +49 30 559 531 75
M +49 179 394 30 92
[email protected]

http://gobo.io
